Print method
Thermal line printingTechnology
Themal Line -
Fonts & Styles
Print Speed
250 mm/secPrint Speed receipt
200 mm/secPrinting Font
ANKColumn capacity receipt
Paper width 80 mm, 48 / 64Character set
95 Alphanumeric, 18 set International, 128 x 43 GraphicCharacters per inch
22.6 cpi / 16.9 cpiDot density
203 DPI x 203 DPIColour Printing
BlackPrinting Characters
Text (incl. Euro symbol), Graphics, Barcode -
Paper
Paper Types
ReceiptPaper size roll paper
79.50 ± 0.50 (W) mm x dia 83.00 mm,
57.50 ± 0.50 (W) mm x dia 83.00 mm -
Interfaces
Interfaces
RS-232, Wired Network, USB 2.0 Type B, Drawer kick-out -
Data Buffer
Data Buffer
4 kB or 45 Bytes -
Power
Power Supply
AC adapter, C1Power Consumption
Standby: 0.1 A, Mean: 1.8 AOperating Voltage
24 V -
General
Product dimensions
140 x 199 x 146 mm (Width x Depth x Height)Product weight
1.7 kgColour
Black (EBCK)Installation
horizontally, vertically, vertically with wall hanging bracket, wall hangingInterface connectors
D.K.D. function (2 drivers)Noise Level
Operation: 55 dB (A)Supported Humidity
Operation 10% – 90%, Storage 10% – 90%Supported Temperature
Operation 5° C – 45° C, Storage -10° C – 50° C -
Reliability
Reliability
60,000,000 MCBF (Lines), 360,000 MTBF (Hours)Auto Cutter Life
1,500,000 CutsPrinter Life
15,000,000 linesPrint Head Life
150 km -
Standards Compliance
EMC Standards
FCC class A, CE marking, EN55022 Class ASafety standards
UL, CSA, TÜV -
Other Features
Cutter
Partial CutSensors
Roll paper cover open sensor, Paper End Sensor -
What’s in the box
What’s in the box
AC cable, CD Manual, Main unit, PS-180, Paper exit guide, Power switch cover, Roll paper, Rubber feet, USB cable, Wall hanging bracket, Warranty document
